AIR-WAP605-AX

Enterprise Wi-Fi 6 Performance
The AIR-WAP605-AX is a high-performance dual-band Wi-Fi 6 (IEEE 802.11ax) in-wall access point designed to deliver fast, reliable wireless connectivity for modern hospitality and multi-room environments. With an aggregate wireless throughput of up to 3.0 Gbps, it supports bandwidth-intensive applications such as HD video streaming, IPTV, VoIP, cloud services, and multiple connected guest devices.

Benefits include:

• Dual-band 2.4 GHz and 5 GHz operation
• Aggregate wireless throughput up to 3.0 Gbps
• Optimized for high-density guest room deployments
• Reliable connectivity for multiple concurrent devices

Advanced Wi-Fi 6 Technologies

Built on the latest Wi-Fi 6 platform, the AIR-WAP605-AX enhances network efficiency, capacity, and user experience through advanced wireless technologies, including:

• OFDMA for improved spectrum efficiency
• MU-MIMO for simultaneous multi-user communication
• Target Wake Time (TWT) for enhanced power efficiency
• Beamforming for improved signal coverage
• Intelligent Airtime Fairness
• Reduced latency for real-time applications

These features ensure consistent performance in environments where multiple wireless devices operate simultaneously.

Integrated 5-Port Gigabit Switch

The AIR-WAP605-AX combines enterprise-class wireless access with a built-in 5-port Gigabit Ethernet switch, providing flexible wired connectivity within each guest room.

The integrated switch includes:

• 1 × Gigabit uplink port with IEEE 802.3at PoE+ input
• 4 × Gigabit downlink LAN ports
• 1 × IEEE 802.3af PoE output portfor powering compatible IP phones, VoIP devices, IoT gateways, or other PoE-enabled equipment

This all-in-one design simplifies room infrastructure while reducing deployment costs and eliminating the need for additional switches.

Transparent Gigabit Pass-Through

The integrated Gigabit Pass-Through port maintains wired network connectivity even if the access point is powered off or unavailable. This ensures uninterrupted network access for connected wired devices, improving service continuity and minimizing downtime.

Flexible Wired Connectivity

Four integrated Gigabit Ethernet downlink ports allow wired devices to connect directly to the network without requiring additional switching equipment.

Ideal for connecting:

• Smart TVs
• IPTV Set-Top Boxes
• IP Phones
• Desktop Computers
• Gaming Consoles
• Printers
• Hospitality IoT Devices

Support for VLAN segmentation enables secure separation of guest, staff, and management traffic.

Simple and Cost-Effective Deployment

Designed to fit standard 86 mm wall junction boxes, the AIR-WAP605-AX installs neatly in place of a conventional wall outlet, preserving room aesthetics while delivering enterprise-grade connectivity.

Using Power over Ethernet (PoE+), a single Ethernet cable provides both power and data, enabling:

• Fast installation
• Reduced cabling requirements
• Quiet, fanless operation
• Lower deployment and maintenance costs

Flexible Operating Modes

The AIR-WAP605-AX supports multiple deployment modes to accommodate a variety of network architectures:

• Fit AP Mode– Controller-managed enterprise deployments
• Fat AP Mode– Standalone operation without a controller
• Bridge Mode– Wireless bridge connectivity for specialized applications

These modes can be easily configured to meet changing business and deployment requirements.

Enterprise Security and Centralized Management

The AIR-WAP605-AX integrates seamlessly with the AirPro Wireless Controller and AirPro Cloud Management Platform, providing centralized provisioning, monitoring, firmware management, RF optimization, and performance analytics. Comprehensive enterprise security features help protect guest and business networks while simplifying day-to-day operations.

Purpose-Built for Hospitality

Purpose-built for modern in-room networking, the AIR-WAP605-AX is ideally suited for:

• Hotels & Resorts
• Guest Rooms & Suites
• Serviced Apartments
• Student Accommodation
• Hospitals & Healthcare Facilities
• Senior Living Communities
• Multi-Dwelling Units (MDUs)

Its combination of enterprise Wi-Fi 6, integrated Gigabit switching, PoE output, and centralized management makes it an ideal solution for delivering seamless wired and wireless connectivity in hospitality environments.
